DC-U6K31WRA

20MP AI Multi-directional Camera

תואם NDAA
  • 4 X 5MP Sensors
  • 4CH Multi-directional Camera
  • Easy installation with DirectIP NVR
  • H.265 and Intelligent Codec
  • Remote Motorized Focus and Zoom
  • PoE (IEEE 802.3at Class 4)
  • IR LED (Distance: 25m / 82ft)
  • IDIS Deep-Learning Analytics (IDLA)
הורדת גיליון מפרט

מפרט טכני

Video - for 4CH
Image Sensor1/2.8" CMOS
Max. Resolution2592x1944
Scanning ModeProgressive Scan
Lens TypeMotorized Vari-focal
Focal Length3.3 ~ 7.02mm
ApertureF1.8 ~ F2.74
Iris ControlFixed Iris
Angular Field of View[4:3]
Wide : 96º(H), 69.8º(V), 127.8º(D)
Tele : 42.4º(H), 31.8º(V), 53.2º(D)

[16;0]
Wide : 96º(H), 51.5º(V), 113.5º(D)
Tele : 42.4º(H), 23.7º(V), 48.7º(D)
Min. IlluminationCOLOR : 0.1 lux @ F1.8
B/W : 0 lux (IR LED ON)
Dynamic Range120dB (True WDR)
Electronic Shutter SpeedAuto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15)
Day and NightYes (ICR)
IR Distance (LEDs)25m / 82ft (3ea per unit)
Image SettingExposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control)
Mirroring / PivotHorizontal / Vertical / Pivot
De-fogYes
Privacy Masking8 Zones
Intelligent VideoObject Metadata: Human, Vehicle, Face
IDLA: Object Detection, Intrusion, Loitering, Line Crossing, Face Detection
Basic: Video Motion Detection, Active Tampering Alarm
Pan/Tilt/Rotate
Pan Range0° ~ 360°
Tilt Range0° ~ 80°
Rotate Range0° ~ 90°
רשת
Video CompressionH.265, H.264 (MP), M-JPEG
Intelligent CodecYes
Bitrate ControlH.265 - CBR / VBR, H.264 - CBR / VBR
Audio CompressionOpus, ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law
Two-way AudioYes
IP Camera ProtocolDirectIP 2.0, ONVIF Profile S/T
Max. Frame Rate4:3 mode : 30ips : 2592 x 1944(WDR)
16:9 mode : 30ips : 2592 x 1456(WDR)
Supported Resolution4:3 : 2592x1944, 1920x1440, 1280x960, 640x480
16:9 : 2592x1456, 1920x1080, 1280x720, 640x360
Multi-video StreamingQuadruple Streaming
Network ProtocolsDirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2
SecurityFIPS 140-3 Level 3, Digest authentication, Password Protection, Brute force delay protection, User access log, IP Filtering, IEEE802.1x(EAP-TLS), Chained Fingerprint, SSL Encryption, HTTPS Encryption
EthernetRJ45 (10/100/1000BASE-T)
Recording Session Buffer (NLTSrec)Yes (Up to 60MB)
Edge StorageMicro SD/SDHC/SDXC,UHS Speed Class 3, Smart Failover (Up to 512GB)
אזעקה ואירועים
Trigger EventMotion Detection, Alarm in, Audio detection, Tampering, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection
Event NotificationRemote S/W, Email (with Image)
Audio AlarmYes
Audio In / Out1 / 1
Alarm In / Out1 / 1
סביבתי
Vandal Proof CasingIK10
Outdoor ReadyIP67, NEMA4X
Operating Temperature-40°C ~ +55°C (-40°F ~ +131°F)
*Starting up at above -20°C (-4°F)
Operating Humidity0% ~ 90%
חשמל
Power SourcePoE, IEEE 802.3at(Class 4)
Power ConsumptionPoE, IEEE 802.3at(Class 4), 21W
ApprovalFCC, CE, KC, UL
מכני
DimensionsØ258 x 112mm(Ø10.2” x 4.4”)
Weight2.8kg (6.2lb)

אביזרים תואמים

סביבה

Wall Mount

Wall mount bracket and matching adapter combination for vertical exterior or interior walls.

Wall MountDA-WM1400
+
Multi-imager Mount AdapterDA-MA4400
סביבה

Ceiling Mount

Ceiling mount and pendant adapter combination for overhead installation.

Ceiling MountDA-CM1300
+
Multi-imager Mount AdapterDA-MA4400
Ceiling MountDA-CM1500
+
Multi-imager Mount AdapterDA-MA4400
סביבה

Corner Mount

Corner mount adapter combination for structure edges and corners.

Wall MountDA-WM1400
+
Corner MountDA-RM1100
+
Multi-imager Mount AdapterDA-MA4400
סביבה

Pole Mount

Pole mount adapter combination for vertical cylindrical or square poles.

Wall MountDA-WM1400
+
Pole MountDA-LM1100
+
Multi-imager Mount AdapterDA-MA4400

קבצים להורדה

[גיליון נתונים] DC-U6K31WRA Datasheet הורדה
